Totaline® Contactor 1 Pole, 208/240Vac Coil, 40FLA, 50RA, Lug Terminals

Totaline  |  SKU: Item P282-0411

$17.98

Free In-Store Pickup

Ships In 1 Business Day

Same-Day/Next-Day Local Delivery

Description

Electrical
FLA 40
Hertz 60
Voltage 240/277/480/600
Safety Standards
California Prop 65 Yes
Specification
Coil Voltage 24Vac
Poles 1
Weights and Dimensions
Operating Weight (lbs) 0.52
Exterior Dimensions (D) (inches) 1.800000
Exterior Dimensions (W) (inches) 2.910000
Exterior Dimensions (H) (inches) 1.250000
Shipping Weight (lbs) 2.000000



FEATURES & BENEFITS

• 1 Pole.
• FLA: 40.
• Resistive Amps: 50.
• Coil Voltage: 24Vac.
• 200LRA @ 240Vac, 160LRA @ 480Vac, 120LRA @ 600Vac.
• Terminal Type: Lugs.
• Insulation: Class B.
• 4 Quick Connections Per Pole.
• Temperature °F: -40 to 150.
• Temperature °C: -40 to 65.
• Silver Cadmium Oxide Contacts.
• UL 508 File NO. E227250.
