Fasco D158 1/5-1/6-1/7 HP Fan & Blower Motor 1050 RPM 3 Speed 115 Volts
Regular price
$139.50
Product Location:
Couldn't load pickup availability
Ships in 1 business day
Get quick delivery on all in-stock orders - Shipments processed within 1 business day.
Got questions?
Feel free to get in touch
Ask an expert
Earn [points_amount] when you buy this item.
Fasco D158 1/5-1/6-1/7 HP Fan & Blower Motor 1050 RPM 3 Speed 115 Volts 42 Frame OAO
- Direct Drive Blower Motor
- 5" Diameter - 42 Frame
- Shaded Pole
- Thermally Protected
- Open Air Over
- Class A Insulation, 40°C Ambient
- Sleeve Bearing
- 1/2" Diameter Shaft with Flat
- 36" Leads
- Resilient Ring Mounting, Belly Band
General Specifications
| UPC: | 815585028703 | Weight: | 12 LB |
| Packaged Length: | 5.13 IN | Packaged Width: | 5.13 IN |
| Packaged Height: | 10 IN |
Nameplate Specifications
| Output HP: | 1/5-1/6-1/7 Hp | Output KW: | 0.15 kW |
| Frequency: | 60 Hz | Voltage: | 115 V |
| Current: | 6.7/5.3/4.7 A | Speed: | 1050 rpm |
| Service Factor: | 1 | Phase: | 1 |
| Duty: | Air Over | Insulation Class: | A |
| Frame: | 42 | Enclosure: | Open Air Over |
| Thermal Protection: | Thermally Protected | Ambient Temperature: | 40 °C |
| UL: | Recognized | CSA: | Y |
| CE: | N |
Technical Specifications
| Electrical Type: | Shaded Pole | Starting Method: | Across The Line |
| Poles: | 6 | Rotation: | Clockwise Shaft End |
| Mounting: | Resilient Rings | Drive End Bearing: | Sleeve |
| Opp Drive End Bearing: | Sleeve | Frame Material: | Na |
| Shaft Type: | Flat | Overall Length: | 8.79 in |
| Shaft Diameter: | 0.500 in | Shaft Extension: | 4.16 in |
- Type Motors
- Vendor FASCO
- Sku Item # 41223949 | Model # D158
- Specifications 5" Diameter - 42 Frame Shaded Pole Thermally Protected Open Air Over Class A Insulation, 40°C Ambient Sleeve Bearing 1/2" Diameter Shaft with Flat 36" Leads
- Weight 10 lb
- Material Steel
- Style Direct Drive Blower Motor
- Returnable 10-Day
- Warranty None
- Saber Sales Exclusive No
- CA Residents Prop 65 Warning(s) Yes
