Century® 9722 MultiFit® Condenser Fan Motor
Century® 9722 MultiFit® Condenser Fan Motor is backordered and will ship as soon as it is back in stock.
Description
Description
Features:
- Replaces Hundreds of 1/6 to 1/4 HP Applications
- All angle mount
- Class B insulation
- Reversing plug
- Totally enclosed
- 36 inch leads
- 60C ambient
- Single speed
- Multi-mounting system
- Double sealed ball bearings
- Energy efficient PSC design
- One simple connection eliminates the need to select various horsepower or change capacitor sizes
Specifications:
- H.P. -1/4,1/5-1/6
- Speeds 1
- Amps 2.00-1.20-1.00
- Rotation Reversible
- Capacitor POC7.5
- RPM 1075 - 1145 - 1165
- Bearings Ball
- Diameter (In.) 5
- Enclosure Totally Enclosed
- Mounting Stud or Belly Band
- Service Factor 1.00
- Shaft Length (In.) 3
- Motor Type Permanent Split Capacitor
- Frame 42
- Overload Automatic
- Phase 1
- Shaft Diameter (In.) 1/2
- Shafts 1
- Hertz 60
- Shaft Dimension (In.) 1/2 x 3
- Length Less Shaft (In.) 4.5
- Voltage 208-230
- Capacitor Required 7.5MFD/370V
This motor can replace manufacture/motor numbers:
Mars, GE 02244, 02245, 02246, 02247, 02250, 02251, GE 2244, 2245, 2246, 2247, 2250, 2251, 5KCO29JCA327S, 5KCP29ECA033, 5KCP29ECA321, 5KCP29FCA174, 5KCP29FCA174, 5KCP29FCA322S, 5KCP29HCA055 , 5KCP29HCA055BS, 5KCP29HCA055CS, 5KCP29HCA092, 5KCP29HCA092BS, 5KCP29HCA094, 5KCP29HCA094CS, 5KCP29HCA162, 5KCP29HCA162AS, 5KCP29HCA326S, 5kcp29jca324s, 5KCP29JCA325S, Goodman B13400252, Lennox 31L1901, Fasco G2244, G2245, G2246, G2247, Trane CPND151060P01, D151060P01, Gentec, Fasco G2247, F42BS9A01
